| year | 2018 |
| typology | Wall luminaire for facade lighting with light emission on four sides |
| mounting | To wall by fixing base |
| width | 125 mm / 4.92″ |
| depth | 125 mm / 4.92″ |
| length | 95 mm / 3.74″ |
| construction | Fixture: turning and milling aluminum. Lens: PMMA.Protective glass in PMMA complete with silicone gasket |
| finishes | Powder coated |
| IP rating | IP67 |
| lamp quantity | 4 |
| lamp type | Power LED. Remote power supply not included |
| lamp wattage | 8W at 48V DC (2W per side) |
| special features | DMX addressable |
| beam angle | 3° |
| colour temperatures | 3000K CRI93 |
| lamp lumens | 560lm |
| lamp efficacy lm/W | 70lm/W |
| lumen maintenance | 50.000hrs lifetime with lumen maintenance at L70 |
| dimming options | DMX |
| certifications | CE |
